Product Details:
|
| Material: | LDPE | Thickness: | 1-100mm |
|---|---|---|---|
| Shape: | Sheet Or Roll | Density: | 25-330kg/m3 |
| Usage: | Car,automotive | Tear Strength: | 150(min)GMF |
| Width: | 1m-2m, Customized | Size: | Custom Size |
| Product Name: | Expandable Polyethylene EPE Foam Materials | Function: | Waterproof,Anti-impact |
| High Light: | 100mm Thickness PE Foam Sheet,150 Min GMF PE Foam Sheet,XLPE Expandable PE Foam |
||
|
||||
| Property | Standard | Unit | Value | |
| Density | - | Kg/m³ | 100.00 | |
| Tensile Strength | Transverse | ISO-1798 | MPa | 0.71~0.74 |
| Longitudinal | 0.93~1.00 | |||
| Elongation | Transverse | ISO-1798 | % | 191.50~212.30 |
| Longitudinal | 214.40~237.10 | |||
| Tearing Strength | Transverse |
ISO-8067
|
Kn/m | 3.58~3.65 |
| Longitudinal | 4.46~4.52 | |||
| Operating Temperature Range | Internal | °C | (-40,+80) | |
| Water Absorption % Volume (Maximum) | Internal | % | 0.20 | |
| Thermal Conductivity | JIS A1412-2 | W/mK | 0.095 | |
| Shore - C | ASTM D2240 | °C | 55 | |
| Flammability | FMVSS302 | mm/min | - | |
1. Thermal insulation and soundproofing material for car
Material: XPE
Density: 30B (33 kg/m³)
Thickness: 3mm, 4mm, 5mm
Processing method: Adhesive (Included)
Advantage: Adhesive foam for easy decroration, have good soundproof and thermal insulation performance. Fire retardant is available.
Material: XPE, IXPE Foam
Density: 10B (100 kg/m³), 15B (66 kg/m³)
Thickness: 5mm, 6mm, 7mm
Processing method: Heat pressing and seaming
Advantage: It's used in the middle layer of car floor. The most common product is combination of PVC materials. Easy to process and laminate with other materials to enhance waterproof and insulating properties.
Material: XPE, IXPE Foam
Density: 20B (50 kg/m³), 25B (40 kg/m³), 30B (33 kg/m³)
Thickness: 5mm
Processing method: Heat pressing
Advantage: Excellent insulation materials and building-up properties.
Material: IXPE, IXPP
Density: 15B(66 kg/m³)
Thickness: 4mm, 5mm
Processing method: Heat pressing & die cutting
Advantage: Processing with flexible IXPE or IXPP foam material to prevent vibration and reduce the heat.
Material: IXPE, XPE Foam
Density: 30B (33 kg/m³), 35B(28 kg/m³)
Thickness: 3mm, 4mm, 5mm, 6mm
Processing method: Heat pressing
Advantage: Extremely easy to cut into the size you want with shockproof protection and noise reduction properties.
Material: XPE, IXPE Foam
Density: 8B (125 kg/m³), 10B (100 kg/m³), 15B (66 kg/m³), 20B (50 kg/m³)
Thickness: 2mm, 3mm, 4mm
Application: Door waterproof strip, water-repellent film
Processing method: Thermal vacuum forming
Advantage: The closed cell foam structure provides noise reduction and excellent waterproof property.
Qur services
Factory direct selling with competitve price, sooner leadtime,better customized services.
Samples in stock can be arranged in one working day.
Company info
CYG TEFA Co.,Ltd is a subsidiary of CYG Group Ltd (stock code:600525).
CYG TEFA Co.,Ltd has 17 years of production experience.We're the biggest and the most professional irradiation crosslinked polyethylene conductive foam manufacturer in China and has the most complete crosslinked polyethylene foam products. Our main products are Crosslinked PE foam material, IXPE foam, XPE foam, Conductive IXPE foam; ESD foam tray, ESD packing material; Beach mat,camping mat,sleeping mat, yoga mat;etc
