Product Details:
|
| Material: | PE | Thickness: | 19 Mm |
|---|---|---|---|
| Size: | As Request | Structure: | Closed Cell |
| Density: | 28.6kg/m3 | Hardness: | 13~18 Degree |
| Tensile Strength: | >0.2 | Elongation: | >80% |
| Tearing Strength: | >1.2 KN/m | Times: | 35 Times |
| Size Change Rate: | <-6% | Water Absorption 23 Degree 24h: | <0.5% |
| Thermal Conductivity: | <=0.4w/m.k | Port: | Shenzhen Port |
XPE foam is a kind of PE Foam,made by high temperature foaming after extrusion,cross-linked and foaming at the same time.it is the ideal foam for applications where support and durability are crucial.
XPE foam is a kind of polymer material with good and independent obturator foramen, and smoothly surface and good elasticity, meanwhile it is also full of high mechanics intensity and good heat insulation, good waterproof, well resistant to aging, to high temperature, to chemical corrosion and different environments. The PE foam can be processed, easy and complex ones are both ok,or it also can be compounded with some other material to conglutinate.
Single foaming structure can reduce the loss of heat between air convection, suitable for making heat preservation pipes and boards. Good anti-dew capability, suitable for humid environments like refrigerators, air-conditioners and ice houses, etc.
Closed-cell foam, non-water-absorbing, moisture-proof.
Soft texture and good resilience enable foam to have a shock absorption effect and play a protective role.Semi-hard quality foams have good rebound capabilities after strong impact, suitable for the packing of instruments, semi-conductors and electronics, etc.
Good sound and noise absorption capability, suitable for sound absorption and insulation parts of automobiles, electro-motors and other equipment and environments with loud noises.
Conductivity of this material is 0.034 w / mk at an average° C. As this product has high heat-releasing ratio, it can get the same heat-preservation effect at less half thickness of other insulating product under the same condition, saving not only space but also cost.
Good pliability
Dew resistance
Easy to fabricate
Anti-slip/anti-skidding
Extremely low odor
Non toxic Flexibility
Safety and eco-friendly
Anti-aging
Weather resistance
Cost-effective
Building, civil field, roof, wall heat insulation, heat preservation, buffer, condensation prevention, waterproof, prevent leakage, anti-corrosion materials; Civil various base materials;
Antifreeze, shockproof buffer materials; Interior decoration, wallpaper, mattress material, etc.
Vehicle areas: Automobile inner decoration, ceiling, instrument panel, cover the old board, cooler, floor etc materials; The train trunk lining, seats, floor, decorative materials; Vehicles with wiring protection, seat, decoration materials.
The changes in temperature room machines, water tank, reservoir of insulation materials; Chemical plant pipe, water pipe, water pipe antifreeze and heat preservation material; The solar energy water heater, energy saving of heat insulation materials; Central air conditioning, air conditioner with heat insulation material, etc.
culture and sports, general cargo areas: School teaching materials, children's toys, sports with all kinds of cushion, surfing board, swimming jacket, float and buffer materials; Kitchen sink, mat, bath tank lid and slippers, hats, etc.
Seedling, the miao sheets; Temperature insulation materials; Stabling house term sheet, cold storage insulation materials; Fruit packing.
Glass, ceramics and fragile goods packaging, electronic appliances, components, household electrical appliances protection packaging materials, lighter, clocks and watches, all pen protection materials, medical equipment transport buffer materials; Furniture transportation protection materials.
Aircraft interior decoration materials, ship in thermal insulation, buffer, buoyancy, safe air conditioning until the special materials; The train thermal insulation, decorative materials; Ice truck, living fresh car insulation materials; Natural gas, gas pipe protection materials.
1. NFR(Normal fir retardant ):normal colors(gray,black,white) is $2.53~2.82 per m2/mm,other colors is $2.7~3.02
2. FXPE-B :normal colors(gray,black,white) is $2.67~2.98 per m2/mm,other colors is $2.86~3.19
3. FXPE-A :normal colors(gray,black,white) is $2.64~2.95 per m2/mm,other colors is $2.83~3.15
4. FXPE-H :normal colors(gray,black,white) is $2.87~3.2 per m2/mm,other colors is $3.07~3.43
CYG TEFA Co., Ltd has 17 years of production experience. We're the biggest and the most professional irradiation cross-linked polyethylene conductive foam manufacturer in China and has the most complete cross-linked polyethylene foam products.
Our main products are Cross-linked PE foam material, IXPE foam, XPE foam, Conductive IXPE foam; ESD foam tray, ESD packing material; Beach mat, camping mat, sleeping mat, yoga mat; etc.
CYG TEFA offers the best solution for polyethylene foam production based on long experience in the developing ,manufacturing PE foam.All the service are focused on quality of products and satisfied our customer.
We are committed to developing,manufacturing and selling cross-linked PE foam.
Over the years,we have developed 3 production bases in Shenzhen,Hangzhou,Chongqing,and 8 production lines of all kinds,with annual production capacity of 4000 tons
All our products can be used for thermal insulation,waterproof,shockproof,etc. and also our products get the UL, ISO, SGS, Rohs, Reach , CE approval.
Our clients are iPhone, Samsung, Gree, Haier, TCL, Adidas, Nike, Flextronics, General Motors, BYD, PPL, etc. Now, we have 2 factories and 17 production lines...
And we have 11 production lines for production.Hope to cooperate with you.
CYG has perfect quality control equipment and strict quality test procedure to ensure the quality and safety.
Introduction of Korean professional equipment and technology to meet customers' quality needs.
Factory direct selling with lower price, sooner leadtime, better customized service.
Samples in stock can be arranged in one working day.
Low-density polyethylene foam has numerous applications because of its many desirable properties including water-resistance, chemical resistance, energy-absorbance, buoyancy and cushioning characteristics. Compressive strength is greater in denser foams, decreasing as density decreases. Low-density foams tend to exhibit more compressive creep, meaning they become less thick over time, than higher-density foams.
Our insulation have good performance on heat-resistant, fireproof, waterproof, heavy duty, lightweight, Eco-friendly and so on.
If use indoor, can be 5-8 years; if use outdoor, can be 1-3 years; if use inside the wall, can be permanent.
Replacement. If there are some defective foam products, we usually credit to our customer or replace in next shipment.
We are a professional company engaged in the field more than 15 years with rich experience , advanced technology and high-tech employees.
Our products are produced according to customers' requirements, size and color can be customized. If you have any question about us, please feel free to contact us, we will response you as soon as possible.
