Product Details:
|
| Density: | 28-200 Kg/m 3 | Structure: | Closed Cell |
|---|---|---|---|
| Thickness: | 2-100 Mm | Max Width: | 1.5 M |
| Color: | Black White Brown Yellow Blue,any Color | Characteristic: | Durable,waterproof,high Environmental |
| Application: | Constriction | Function: | Thermal Preservation |
| Certificate: | SGS.REACH.ISO9001.ROHS | Package: | Plastic Bags Or Customized |
| Port: | Shenzhen |
Physical, irradiation cross linked polyethylene foam
PE foam can be divided into EPE, PEF, XPE, IXPE and LDPE, the XPE and IXPE are most widely used.
Two major types of crosslinked PE foam are:
1.Physically Crosslinked polyethylene foam(IXPE FOAM) is very fine celled microcellular foam. Iriadiated crosslinked foam is used for medical applications, heart forming, and high end protective packaging and consumer products. This foam can actually be printed on very clearly.
2.Chemically crosslinked polyethylene foam(XPE FOAM) also has good physical properties, but has a larger more random cell structure. Chemically crosslinked foam can also be used for packaging, heat forming and a large variety of applications.
Features:
1.light weight, good elasticity
2. weatherproof and waterproof
3. flame retardant
4. sound absorption
5. heat insulation
6. thermal insulation
7. elastic and flexibility
8. shock absorption
Specifications
MOQ:1) 3mm-4mm thickness,MOQ3000sqm
2)5mm-7mm thickness,MOQ2000 sqm
3)thickness more than 8mm,MOQ 1000 sqm
delivery date from the Date of Order:15-20 workingdays
Advantages
closed cell Cross linked polyethylene foam
1. Heat Insulation:
Singlefoaming structure can reduce the loss of heat between air convections, suitable for making heat preservation pipes and boards. Good anti-dew capability, suitable for humid environments like refrigerators, air-conditioners and ice houses, etc.
2. Cushion Capability: Semi-hard quality foams have good rebound capabilities after strong impact, suitable for the packing of instruments, semi-conductors and electronics, etc.
3. Sound Absorption:
Good sound and noise absorption capability, suitable for sound absorption and insulation parts of automobiles, electro-motors and other equipment and environments with loud noises.
4. Shaping Capability:
Good heat endurance and ductility capability with even density, suitable for making deep interior parts like shaping in vacuum and hot environments, like the air conditioning vaporizing tank of automobiles, hot-shaped peak canopy of vehicles and shoes, etc.
5.Good chemical, oil, acid and alkali durability capabilities.
It is safe and odorless, easy for machining and casting, and can be mixed with many other materials. It has a wide developing area as a new environmentally-safe material.
Our services
Factory direct selling with competitve price, sooner leadtime,better customized services.
Samples in stock can be arranged in one working day.
Company info
CYG TEFA Co.,Ltd has 14 years of production experience.We're the biggest and the most professional irradiation crosslinked polyethylene conductive foam manufacturer in China and has the most complete crosslinked polyethylene foam products. Our main products are Crosslinked PE foam material, IXPE foam, XPE foam, Conductive IXPE foam; ESD foam tray, ESD packing material; Beach mat,camping mat,sleeping mat, yoga mat;etc
Now, we have 2 factories and 8production lines. .
company website: www.cygtefa.com
Certification Authentification
ISO9001,ROHS,SGS,UL ,REACH,etc.
PRODUCT VIEW English edition
Foam status | tubes,sheets and blocks, rolls | |
Packaging Details | Regular packing with PE bag outside, foam wrapped inside
| |
Delivery Details | Sample | 3-6 Work Days |
| Order | 4-15Days |
Support customized logo &package | ||
FAQ
1)What is closed-cell?
A: Polyethylene foam is closed-cell, meaning it consists of cells so tightly packed together that it gives the appearance of one uniform structure.
The reality is that the individual cells within polyethylene foam do not physically connect to one another.
This cellular formation is similar to fish caught in a fisherman's net.
2)Why choose Low-density polyethylene foam?
A: Low-density polyethylene foam has numerous applications because of its many desirable properties including water-resistance, chemical resistance, energy-absorbance, buoyancy and cushioning characteristics. Compressive strength is greater in denser foams, decreasing as density decreases. Low-density foams tend to exhibit more compressive creep, meaning they become less thick over time than higher-density foams.
3)How can I know the suitable foam density I need?
A: Our PE foam density is between 25 kg/m3 and 240 kg/m3
We can provide the best solution for you according to the application, Density, hardness, thickness.And The free sample is available for your confirmation and text
4) How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (ABC bank) and Paypal, Western Union are the most usual ways we are using for freight fees of PE foam samples.
5) What’s the order procedure?
A: First we discuss foam products details by email or TM.
Then we issue you a PI for your confirmation. You will be requested to do prepaid full payment or deposit before we go into production.
After we get the deposit, we start to process the order. usually takes 7-15days if we don’t have the items in stock.
Before production has been finished, we will contact you for shipment details, and the balance payment. After payment has been settled, we start to prepare the shipment for you.
6)How do you take care when your clients received defective foam products?
A: replacement. If there are some defective foam products, we usually credit to our customer or replace in next shipment.
7)How do you check all PE foam on the production line?
A: We have spot inspection and finished product inspection of our foam materials.We check the PE foam materials when they go into next step production procedure.
