Thermal Insulation Ixpe Foam Material Aluminum Foil Air Conditioning Pe Polyethylene Pipe

Thermal Insulation Ixpe Foam Material Aluminum Foil Air Conditioning Pe Polyethylene Pipe
Thermal Insulation Ixpe Foam Material Aluminum Foil Air Conditioning Pe Polyethylene Pipe

Large Image :  Thermal Insulation Ixpe Foam Material Aluminum Foil Air Conditioning Pe Polyethylene Pipe

Product Details:
Place of Origin: China
Brand Name: CYG
Certification: ISO9001, ISO14001, IATF16949,FMVSS 302,UL94 HF-1,RoHS,CE,etc.
Model Number: NON
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: PE Bag
Delivery Time: 15-20 days
Payment Terms: L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability: 500 tons per month

Thermal Insulation Ixpe Foam Material Aluminum Foil Air Conditioning Pe Polyethylene Pipe

Description
Product Name: IXPE Foam Laminated Closed Cell Polyethylene Foam Blocks Roll Density Density: 28-333 Kg/m3
Thickness: 0.1-100mm Material: LDPE
Thermal Conductivity: 0.03~0.036W/M*K Color: As Per Customer Request

Thermal Insulation Ixpe Foam Material Aluminum Foil Air Conditioning Pe Polyethylene Pipe




Electronic cross-linked polyethylene foam also named Physical crosslinked polyethyele foam, Irradiation crosslinked polyethylene foam.Common abbreviations IXPE foam, IXLPE foam.It is made of low-density polyethylene (LDPE), AC foaming agent and other powders after being melted, mixed and extruded, and then foamed at high temperature. IXPE has finer cells, smoother surface and better mechanical properties than XPE.
Production process: compounding-extrusion-irradiation-foaming.
Note: IXPE foam can be made anti-static (we will talk about anti-static IXPE later), but XPE cannot (theoretically it is possible, but our company does not currently produce).


Feature


· Light weight, good elasticity
· Incumbustible and waterproof
· Flame retardant
· Water absorption, Sound absorption
· Heat isolation
· Elastic and flexibility
· Anti-skidding, shock absorption and cold pressure.



Specifications



Density 200 ± 30 125 ± 15 100 ± 10 66.7 ± 8 50 ± 6 40 ± 4 33.3 ± 3
Hardness 60-70 50-60 45-50 35-45 30-35 2-30 18-25
Water absorption
(23 ° C 24h)g/ cm ³
≤ 0.02 ≤ 0.02 ≤ 0.03 ≤ 0.03 ≤ 0.04 ≤ 0.04 ≤ 0.05
Thermal conductivity ≤ 0.092 ≤ 0.082 ≤ 0.07 ≤ 0.062 ≤ 0.053 ≤ 0.047 ≤ 0.041
Tensile strength(mpa) L ≥ 1.35 ≥ 1.12 ≥ 0.88 ≥ 0.68 ≥ 0.39 ≥ 0.33 ≥ 0.25
  M ≥ 1.08 ≥ 0.89 ≥ 0.71 ≥ 0.56 ≥ 0.33 ≥ 0.25 ≥ 0.20
Tesibility L ≥ 260 ≥ 230 ≥ 210 ≥ 190 ≥ 170 ≥ 160 ≥ 140
  M ≥ 220 ≥ 200 ≥ 185 ≥ 170 ≥ 150 ≥ 135 ≥ 130
Tearing strength L ≥ 5.90 ≥ 4.80 ≥ 3.60 ≥ 2.80 ≥ 1.80 ≥ 1.60 ≥ 1.35
  M ≥ 7.10 ≥ 5.40 ≥ 4.00 ≥ 3.30 ≥ 2.30 ≥ 2.00 ≥ 1.70





Raw material: LDPE, PE foam+Alu foil
Density: 25~333kg/m3
Length: customized
Wide: 70~1800 mm
Thickness:

xpe 2~3mm 3~12mm
Ixpe 0.1~0.5mm 0.5~3mm, 3~10mm
Color: black,white and gray,other colors can be customized
Shore hardness: 10~80 degree
Reflective:96%~97%
Structure:Closed cell
Surface smooth: Alu
Flammability:B1 grade
Refractoriness:100-150 degree
Thermal Conductivity:0.040~0.095 w/m.k
Water Absorption:(23degree,24h) 0.2~0.6%
Tearing Strength: 0.2~1.8 KN/m
Elongation at break :100%~240%
Tensile Strength: 0.2~1.6 Mpa
Compressed distortion: 2%~10%
Size change rate: -4%`-8%
Thermal conductivity: 0.040 ~0.095 w/m.k
Certificate: ISO9001,REACH,ROSH,IATF16949,CE
Packaging:roll, tape, gasket or seal formats






Company info



CYG TEFA is the earliest PE foam manufacturing with scale production in China since 2002.Mainly produce XPE FOAM,IXPE FOAM,IXPP FOAM and ESD PRODUCT(Foam type: PE/EVA/PU/EPE/PP Plastic).Annual production capacity is about 6000 tons.2 bases one in Shen zhen and an other in Huzhou,with total 17 production lines.CYG Management control system: Kingdee / OA / Oracle.CYG have a professional team and technology.More than 30 R&D staff.Through the great variety of our products we provide people with a warm and quiet home and working environment.



  • Management control system: Kingdee / OA / Oracle



  • R & D team

11 employee
Investment rate: 4% to 10%
Responsible for : Improving available product / Technology improving / New product development / New devices



  • On-going project

IXPP project (three years: Proposal stage - Develop - Sampling - Approved product- Small quantity supply for testing
