Product Details:
|
| Product Name: | IXPE Foam Laminated Closed Cell Polyethylene Foam Blocks Roll Density | Density: | 28-333 Kg/m3 |
|---|---|---|---|
| Thickness: | 0.1-100mm | Material: | LDPE |
| Thermal Conductivity: | 0.03~0.036W/M*K | Color: | As Per Customer Request |
Electronic cross-linked polyethylene foam also named Physical crosslinked polyethyele foam, Irradiation crosslinked polyethylene foam.Common abbreviations IXPE foam, IXLPE foam.It is made of low-density polyethylene (LDPE), AC foaming agent and other powders after being melted, mixed and extruded, and then foamed at high temperature. IXPE has finer cells, smoother surface and better mechanical properties than XPE.
Production process: compounding-extrusion-irradiation-foaming.
Note: IXPE foam can be made anti-static (we will talk about anti-static IXPE later), but XPE cannot (theoretically it is possible, but our company does not currently produce).
Feature
· Light weight, good elasticity
· Incumbustible and waterproof
· Flame retardant
· Water absorption, Sound absorption
· Heat isolation
· Elastic and flexibility
· Anti-skidding, shock absorption and cold pressure.
Specifications
| Density | 200 ± 30 | 125 ± 15 | 100 ± 10 | 66.7 ± 8 | 50 ± 6 | 40 ± 4 | 33.3 ± 3 | |
| Hardness | 60-70 | 50-60 | 45-50 | 35-45 | 30-35 | 2-30 | 18-25 | |
| Water absorption (23 ° C 24h)g/ cm ³ |
≤ 0.02 | ≤ 0.02 | ≤ 0.03 | ≤ 0.03 | ≤ 0.04 | ≤ 0.04 | ≤ 0.05 | |
| Thermal conductivity | ≤ 0.092 | ≤ 0.082 | ≤ 0.07 | ≤ 0.062 | ≤ 0.053 | ≤ 0.047 | ≤ 0.041 | |
| Tensile strength(mpa) | L | ≥ 1.35 | ≥ 1.12 | ≥ 0.88 | ≥ 0.68 | ≥ 0.39 | ≥ 0.33 | ≥ 0.25 |
| M | ≥ 1.08 | ≥ 0.89 | ≥ 0.71 | ≥ 0.56 | ≥ 0.33 | ≥ 0.25 | ≥ 0.20 | |
| Tesibility | L | ≥ 260 | ≥ 230 | ≥ 210 | ≥ 190 | ≥ 170 | ≥ 160 | ≥ 140 |
| M | ≥ 220 | ≥ 200 | ≥ 185 | ≥ 170 | ≥ 150 | ≥ 135 | ≥ 130 | |
| Tearing strength | L | ≥ 5.90 | ≥ 4.80 | ≥ 3.60 | ≥ 2.80 | ≥ 1.80 | ≥ 1.60 | ≥ 1.35 |
| M | ≥ 7.10 | ≥ 5.40 | ≥ 4.00 | ≥ 3.30 | ≥ 2.30 | ≥ 2.00 | ≥ 1.70 | |
Raw material: LDPE, PE foam+Alu foil
Density: 25~333kg/m3
Length: customized
Wide: 70~1800 mm
Thickness:
xpe 2~3mm 3~12mm
Ixpe 0.1~0.5mm 0.5~3mm, 3~10mm
Color: black,white and gray,other colors can be customized
Shore hardness: 10~80 degree
Reflective:96%~97%
Structure:Closed cell
Surface smooth: Alu
Flammability:B1 grade
Refractoriness:100-150 degree
Thermal Conductivity:0.040~0.095 w/m.k
Water Absorption:(23degree,24h) 0.2~0.6%
Tearing Strength: 0.2~1.8 KN/m
Elongation at break :100%~240%
Tensile Strength: 0.2~1.6 Mpa
Compressed distortion: 2%~10%
Size change rate: -4%`-8%
Thermal conductivity: 0.040 ~0.095 w/m.k
Certificate: ISO9001,REACH,ROSH,IATF16949,CE
Packaging:roll, tape, gasket or seal formats
