Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation

Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation
Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation
Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation

Large Image :  Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation

Product Details:
Place of Origin: China
Brand Name: CTF
Certification: ISO9001, ISO14001, IATF16949,FMVSS 302,UL94 HF-1,RoHS,CE,etc.
Model Number: Insulated Copper Tube
Payment & Shipping Terms:
Minimum Order Quantity: 3000 SQM
Price: USD 0.29~2.42 Kg/m3
Packaging Details: PE Bag
Delivery Time: 15-20 work days
Payment Terms: L/C, D/P, T/T, D/A, , Western Union, MoneyGram
Supply Ability: 500 tons per month

Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation

Description
Thickness: 0.1-100 Mm Density: 25-330KG/m3
Width: 1-2 M Or Customized Product Name: Polyethylene Foam Insulation
Application: Air Conditioner Ac Tube Insulated Thermal Conductivity: 0.032W/mk
Structure: 100% Closed Cell Flammability: B1 Grade

Air Conditioning Tube Thermal Insulation PE IXPE Foam Material Pipe Insulation

CYG PE Foam is a leading supplier of HVAC products located in Shenzhen, China and serving the trading, contracting, HVAC, MEP, civil, interior works and building material supply of the country. Specializing in Thermal insulation, Acoustic insulation, Adhesives, Sealants, Vapor barriers, Flexible Ducts & Connectors, Fasteners, copper pipes, tools and all kinds of HVAC products. We provide solutions and closed cell cross-linked polyethylene foam (XPE or XLPE or IXPE or IXPP)materials to customers in different countries including China, USA, UK, UAE, Germany, Southeast Asia etc.



Density (kg/m3)Shore Hardnes (°)Water Absorbtion (g/cm2)23℃±2℃,24hThermal Conductivity (w/m.k)
200±3060-70≤0.2≤0.095
125±1550-60≤0.2≤0.084
100±1045-50≤0.3≤0.073
66.7±835-45≤0.3≤0.065
50±630-35≤0.4≤0.055
40±425-30≤0.4≤0.049
33.3±318-25≤0.5≤0.045
28.6±313-18≤0.5≤0.040


Features


  • Saves Energy: retain the temperature of the air they are transporting, reducing energy wastage.
  • Prevents Condensation on Ducts: XPE insulation provides a solid cover around the air ducts.
  • Reduces Noise Transmitted Indoors: XPE can carry sound waves all around the house and carry sounds across rooms such as the noise of the furnace turning on in phases as well.
  • Hot-dipped galvanized steel sheets of lock-forming quality are used for the manufacturing of standard ducts.
  • Ducts are also available in both, stainless steel and Aluminum.
  • All straight ducts have beading all along at a distance of 300 mm between them for reinforce.



Advantages

  • High foaming rate
  • Low density
  • Good elasticity
  • Good toughness
  • Thermal insulation
  • Energy saving
  • Noise reduction
  • Sound insulation
  • Anti-condensation
  • Corrosion and aging
  • Convenient



Air duct insulation

XPE / XLPE insulation pe foam is made by closed cell chemical cross-linked polyethylene foam, adhesive backing and faced with pure aluminum foil and it's flame retardant as well. Widely used in HVAC duct / pipe insulation.
CYG PE foam for ducts are manufactured at our state-of-the-art factory as per customer requirements. All the accessories for example fittings, attachments, components, and other goods are manufactured from the finest grade of material and cutting edge technology. CYG quality controllers check each and in details on well defined quality parameters. With competitive prices, if you need to be, the offered range of ducting is also facilitated with sound proofing and high degree insulation.


CYG PE Foam is a leading supplier of HVAC products located in Shenzhen, China and serving the trading, contracting, HVAC, MEP, civil, interior works and building material supply of the country. Specializing in Thermal insulation, Acoustic insulation, Adhesives, Sealants, Vapor barriers, Flexible Ducts & Connectors, Fasteners, copper pipes, tools and all kinds of HVAC products. We provide solutions and closed cell cross-linked polyethylene foam (XPE or XLPE or IXPE or IXPP)materials to customers in different countries including China, USA, UK, UAE, Germany, Southeast Asia etc.


Company info

CYG TEFA Co., Ltd has 20+ years of production experience. We're the biggest and the most professional irradiation cross-linked polyethylene conductive foam manufacturer in China and has the most complete cross-linked polyethylene foam products. Our main products are Cross-linked PE foam material, IXPE foam, XPE foam, Conductive IXPE foam; ESD foam tray, ESD packing material; Beach mat, camping mat, sleeping mat, yoga mat; etc. Our clients are iPhone, Samsung, Gree, Haier, TCL, Flextronics, General Motors, BYD, PPL, etc. Now, we have 2 factories and 50 production lines...


  • Management control system: Kingdee / OA / Oracle



  • R & D team

11 employee
Investment rate: 4% to 10%
Responsible for : Improving available product / Technology improving / New product development / New devices


  • On-going project

IXPP project (three years: Proposal stage - Develop - Sampling - Approved product- Small quantity supply for testing
