Versatile XPE Closed Cell Foam , Fireproof Foam Insulation Low Thermal Conductivity

Versatile XPE Closed Cell Foam , Fireproof Foam Insulation Low Thermal Conductivity
Versatile XPE Closed Cell Foam , Fireproof Foam Insulation Low Thermal Conductivity Versatile XPE Closed Cell Foam , Fireproof Foam Insulation Low Thermal Conductivity Versatile XPE Closed Cell Foam , Fireproof Foam Insulation Low Thermal Conductivity

Large Image :  Versatile XPE Closed Cell Foam , Fireproof Foam Insulation Low Thermal Conductivity

Product Details:
Place of Origin: China
Brand Name: CTF
Certification: RoHs, CE, REACH, UL , ISO 14001
Model Number: IXPE
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: PE bag
Delivery Time: 15-20 days
Payment Terms: L/C, T/T
Supply Ability: 500 tons per month

Versatile XPE Closed Cell Foam , Fireproof Foam Insulation Low Thermal Conductivity

Description
Density: 25-300 Kg/m3 Thickness: 0.5-100 Mm
Color: Customized Feature: High Efficiency
Material: LDPE Type: Physical Crosslinked
High Light:

closed cell foam insulation roll

,

heat insulation foam



Fireproof XPE Foam Insulation/flame retardant XPE foam/PE foam insulation material For BIG5 EXPO

Features



1. Light weight & intensity and good flexibility, cushioning
2. Invariable if it is attacked repeatedly;
3. Low thermal conductivity and superior heat insulation.
4. Outstanding safety and enviromentally friendly;
5. Easy to install, high efficiency.
6. Cost effective and versatile.
7. Maintenance free.
8. Widely used in dubai


Specifications



Test item Items
  5 Times 8 Times 10 Times 15 Times 20 Times 25 Times 30 Times 35 Times
Density kg/m3 200±30 125±15 100±10 66.7±8 50±6 40±4 33.3±3 28.6±2

Shore

Hardness

60~70 50~60 45~50 35~45 30~35 25~30 18~25 13~18

Water absorbtion

(23℃±2℃,24h)g/cm2

≤0.02 ≤0.02 ≤0.03 ≤0.03 ≤0.04 ≤0.04 ≤0.05 ≤0.05

Heat conductivity

K value w/m.k

≤0.092 ≤0.082 ≤0.072 ≤0.062 ≤0.053 ≤0.047 ≤0.041 ≤0.038



Good ability


CYG foam insulating products with good flexibility make them suitable for bent and irregular pipes in construction, saving both labor force and cost
Vibration Resistance
CYG foam heat-proof and heat-preservation plastic-rubber with high elasticity, can reduce the vibration and resonance of the hot /cold water pipes utmost
Good fire-blocking
This product has fire-blocking and smoke-reducing property, when burned, its density is very low and doesn't melt, without any small fire ball left and with the merit of self-extinguishing.
According to the standard of GB/T 8624 Method for grading flammability of construction material, this is the flame resistant product of grade B1 enabling to secure the satiety
Low conductivity factor
Conductivity of this material is 0.034w/mk at an average° C. As this product has high heat-releasing ratio, it can get the same heat-preservation effect at less half thickness of other insulating product under the same condition, saving not only space but also cost.

Application of XPE Insulation Material:


1) Roof, wall, floor, Attic for heat insulation and thermal insulation;
2) Shells of air conditioner and water heater;
3) Protective coatings of water pipe and ventilating pipe;
4) Machinary packing;
5) Making ice package





CYG Main Product:



Cross-linked PE foam material, IXPE foam, XPE foam, Conductive IXPE foam; ESD foam tray, ESD packing material; Beach mat, camping mat, sleeping mat, yoga mat; etc.



Years Of Experience

17 years of production experience.



Scale Of Factory

17 production lines :9 production lines in Shenzhen and 8 production lines in Huzhou .



Production Capacity

Annual 6000 tons



Why choose us



1.The biggest and the most professional irradiation cross-linked polyethylene conductive foam manufacturer in China

2.The most complete cross-linked polyethylene foam products.

3.Certificate: UL, ISO, SGS, Rohs, Reach , CE



Cooperative Partner



iPhone, Samsung, Gree, Haier, TCL, Nike, Flextronics, General Motors, BYD, PPL, etc.



CYG TEFA offers the best solution for polyethylene foam production,

We supply PE foam in rolls, the length of each roll can be customized to meet customer’s requirement.

The PE foam product can also be provided on the sheet as a request.

Here support foam die- Cutting,Lamination Adhesive ,Sheeting, Perforating & Skiving.

All the service are focused on quality of products and satisfied our customer.
