Closed Cell Physically crosslinked polyolefin foam insulation

Closed Cell Physically crosslinked polyolefin foam insulation
Closed Cell Physically crosslinked polyolefin foam insulation
Closed Cell Physically crosslinked polyolefin foam insulation Closed Cell Physically crosslinked polyolefin foam insulation Closed Cell Physically crosslinked polyolefin foam insulation Closed Cell Physically crosslinked polyolefin foam insulation

Large Image :  Closed Cell Physically crosslinked polyolefin foam insulation

Product Details:
Place of Origin: China
Brand Name: CTF
Certification: SGS
Model Number: PE Foam
Payment & Shipping Terms:
Minimum Order Quantity: 500KG
Packaging Details: PE Bags or Customized
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Closed Cell Physically crosslinked polyolefin foam insulation

Description
Brand Name: Green Thermal Material: LDPE
Density: 25-333kg/m3 Hardness: 20-70
Colour: Customized Colour Application: Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, Supermarket, Warehouse, Workshop, Park, Farmhouse, Courtyard, Construction
Feature: Water-proof Usage: Widely Used

Closed Cell Physically crosslinked polyolefin foam insulation Foamed Pe Polyolefin Foam Insulation Supplier Espuma De Polietileno Precio Ixpe-Soft-Foam Low Density Thin Pe Foam She



Foam Type: XPE FOAM / XLPE FOAM
Property
Standard
Unit
Value
Density
-
-
Kg/m³
33.33
Tensile Strength
Transverse
ISO-1798
MPa
0.22~0.23

Longitudinal


0.29~0.31
Elongation
Transverse
ISO-1798
%
90.30~100.00

Longitudinal


87.20~90.40
Tearing Strength
Transverse
ISO-8067
Kn/m
1.31~1.46

Longitudinal


1.71~1.80
Compression 25%
ISO-3386-1
kPa
31.20
Compression 40%
ISO-3386-1
kPa
58.80
Compression 50%
ISO-3386-1
kPa
90.80
Compression Set 25% 0.5H
ISO-1856
%
16.00
Compression Set 25% 24H
ISO-1856
%
9.80
Operating Temperature Range
Internal
°C
(-40,+80)
Water Absorption % Volume (Maximum)
Internal
%
0.50
Thermal Conductivity
JIS A1412-2
W/mK
0.045
Shore - C
ASTM D2240
°C
19
Flammability
FMVSS302
mm/min
-



Moistureproof High Quality Fireretardant Heat Insulation Physically Cross-Linked Polyethylene Polyolefin Foam Xpe Foam

Closed Cell Physically crosslinked polyolefin foam insulation 0
Closed Cell Physically crosslinked polyolefin foam insulation 1
Closed Cell Physically crosslinked polyolefin foam insulation 2
Performance
Closed Cell Physically crosslinked polyolefin foam insulation 3



Heat Insulation

Single foaming structure can reduce the loss of heat between air convection, suitable for making heat preservation pipes and boards.



Waterproof

Closed-cell foam, non-water-absorbing, moisture-proof.



Shock absorption

Soft texture and good resilience enable foam to have a shock absorption effect and play a protective role.Semi-hard quality foams have good rebound capabilities after strong impact.



Sound absorption

Good sound and noise absorption capability.

Closed Cell Physically crosslinked polyolefin foam insulation 4
Fire retardancy
This product has fire-blocking and smoke-reducing property, when burned, its density is very low and doesn't melt, without any small fire ball left and with the merit of self-extinguishing.



Low conductivity factor

Conductivity of this material is 0.032 w / mk at an average° C. As this product has high heat-releasing ratio, it can get the same heat-preservation effect at less half thickness of other insulating product under the same condition, saving not only space but also cost.

Application
Closed Cell Physically crosslinked polyolefin foam insulation 5



Construction & building

Roof reflective heat insulation

1.Material:XPE foam or IXPE foam faced with aluminum foil both side.(aluminum foil-xpe/ixpe-aluminum foil)

2.Density:25-33.3kg/m3

3.Thickness:4mm,6mm,7mm,8mm,10mm.

4.Wide:1350mm/1500mm

5.Fire resistant: yes

6.Certificate:ASTM1530

Underlay

1.Material:IXPE foam

2.Density:33.3kg/m3 ,66.7kg/m3, 100 kg/m3.

3.Thickness:1mm,2mm,3mm.

Floating floor sound insulation

1.Material:IXPE foam

2.Density:50kg/m3 ,66.7kg/m3

3.Thickness:5mm.

Closed Cell Physically crosslinked polyolefin foam insulation 6
HVAC Insulation
1.Material:Xpe or IXPE one side faced with aluminum foil one side faced with glue. (aluminum foil-xpe/ixpe-glue)
2.Density:25-33.3kg/m3
3.Thickness:10mm 12mm 13mm 15mm 19mm 25mm 30mm
4.Wide:1m/1.2m
5.Length:15m/20m
6.Fire retardent: yes
7.Certificate:BS476
8. Glue coated PE foam laminate with aluminum foil, which increased the thermal conductivity and enhances insulation properties.
Product Processing
Closed Cell Physically crosslinked polyolefin foam insulation 7
Closed Cell Physically crosslinked polyolefin foam insulation 8
Free Sample
Let us konw your density, thickness, color, and application to GET FREE SAMPLES!
Company Profile
Closed Cell Physically crosslinked polyolefin foam insulation 9



CYG TEFA CO.,LTD

CYG TEFA CO.,LTD is an affiliate of the listed company WOER (Shenzhen: 002130). Established in December 2002, CYG is committed to the research and development, production and sales of cross-linked PE and PP foam materials, and is a national high-tech enterprise. There are two bases in Shenzhen and Huzhou, with more than ten various production lines with an annual production capacity of more than 6,000 tons; The main products are: ESD, XPE, IXPE, IXPP and various composite materials based on XPE, IXPE, IXPP ; Widely used in electronic communications, automotive, air-conditioning refrigeration, construction, sports protective gear, medical supplies and other industries, products are sold to many regions around the world.

Factory Tour
Closed Cell Physically crosslinked polyolefin foam insulation 10



Granulation workshop

Closed Cell Physically crosslinked polyolefin foam insulation 11



Extrution line

Closed Cell Physically crosslinked polyolefin foam insulation 12



Horizontal foaming workshop

Closed Cell Physically crosslinked polyolefin foam insulation 13



Vertical foaming workshop

Closed Cell Physically crosslinked polyolefin foam insulation 14



Cutting machine

Closed Cell Physically crosslinked polyolefin foam insulation 15



Warehouse

Closed Cell Physically crosslinked polyolefin foam insulation 16



Laboratory

Closed Cell Physically crosslinked polyolefin foam insulation 17



Laboratory

Closed Cell Physically crosslinked polyolefin foam insulation 18



Laboratory

Certificate
Closed Cell Physically crosslinked polyolefin foam insulation 19
Closed Cell Physically crosslinked polyolefin foam insulation 20
Closed Cell Physically crosslinked polyolefin foam insulation 21
Closed Cell Physically crosslinked polyolefin foam insulation 22
Exhibition
Closed Cell Physically crosslinked polyolefin foam insulation 23
Fire Retardant Materials Expanding Foam Heat Reflective Aluminium Foil Insulation Blocks Polyethylene Roll Ixpe Foam Tape
