Product Details:
Place of Origin: Guangdong, China (Mainland)
Brand Name: CTF
Certification: ISO9001, ISO14001, IATF16949,FMVSS 302,UL94 HF-1,RoHS,CE,etc.
Model Number: Green thermal
Payment & Shipping Terms:
Minimum Order Quantity: 3000 SQM
Price: $0.72 - $8.16 / SQM
Packaging Details: PE bags or customized
Delivery Time: 16-25 Work days
Payment Terms: L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability: 500 tons per month

Reflective Foam Core Insulation Shield Heat Shield Thermal Insulation Shield Vapor Barrier WaterProof Meets Fire Codes

Description
Color: Silver,Black,blue And So On Application: Construction,Roof/Wall/Floor
Thickness: 1-100mm(sheet Or Roll) Material: Ldpe
Density: 25-333KG/m3 Feature: Cold Resistant,flexible Soft Insulation,waterproof. Soundproof Eco-friendly And So On.,thermal Insualtion,Fireproof

Reflective Foam Core Insulation Shield Heat Shield Thermal Insulation Shield Vapor Barrier WaterProof Meets Fire Codes





Closed Cell Cross Linked Rolls & Laminated Sheets Rolls, sheets and multi-layer laminated blocks manufactured from cross linked closed cell PE foam exhibit all the attributes of the above with the exception of being slightly coarser in cell structure. Rolls are typically supplied as skin/skin or skin/cell formats, whilst sheets are available as skin/skin, skin/cell or cell/cell formats. They are typically used for construction joints, packaging of all descriptions, industrial seals and gaskets.This type of PE foam can be easily thermoformed, its water absorption is low, the thermal insulation values are very good, and it has high vibration damping, small water vapour permeability, resists bad weather conditions and is generally resistant to chemicals.





Thermal Insulation Foam

XPE Foam Insulation/ polyethylene Foam Insulation/ Polyolefin Foam Insulation

  • XPE foam+pure aluminum foil or coated aluminum foil
  • Reflecting up to 97% of radiant heat
  • Excellent fire properties
  • Excellent acoustic insulating properties
  • Environmentally/ Eco-friendly and fibre-free
  • Foam Density: Standard 33.3±3kg/m3(Various options available 28-300Kg/m3)
  • Width:1-1.6meter, Length 15-50meter
  • Thickness:1-15mm with single layer, Max 60mm after lamination.
  • Color:grey, black,White
  • Adhesive self strong adhesive lamination aluminum Foil Pure aluminum Foil/ Coated aluminum foil fire-resistance available in Class A,Class B.



Specifications



  • Foam Type: XPE FOAM / XLPE FOAM
Property Standard Unit Value
Density - Kg/m³ 100.00
Tensile Strength Transverse ISO-1798 MPa 0.89~0.90
  Longitudinal     0.98~1.04
Elongation Transverse ISO-1798 % 130.30~148.50
  Longitudinal     130.00~158.20
Tearing Strength Transverse

ISO-8067


Kn/m 5.87~6.00
  Longitudinal     6.22~6.54
Compression 25% ISO-3386-1 kPa 185.20
Compression 40% ISO-3386-1 kPa 252.40
Compression 50% ISO-3386-1 kPa 316.80
Compression Set 25% 0.5H ISO-1856 % 7.10
Compression Set 25% 24H ISO-1856 % 3.30
Operating Temperature Range Internal °C (-40,+80)
Water Absorption % Volume (Maximum) Internal % 0.30
Thermal Conductivity JIS A1412-2 W/mK 0.073
Shore - C ASTM D2240 °C 55
Flammability FMVSS302 mm/min -




Advantages



  • High foaming rate
  • Low density
  • Good elasticity
  • Good toughness
  • Thermal insulation
  • Energy saving
  • Noise reduction
  • Sound insulation
  • Anti-condensation
  • Corrosion and aging
  • Convenient



Roof Insulation Foam

XPE or IXPE double sides laminated with aluminum foil, with advanced thermal performance.

reflecting up to 95% radiant heat, allowing for cooler internal conditions in hot and humidclimates, also it has great property of flame retardant.

Excellent for building’s insulation, like sheds, workshops, factories etc.

  • Moisture barrier, water-proof, heat insulation, energy saving
  • Light, soft, dust-free, flame retardant, easy cutting and installing
  • Noodor, environmentally-friendly
  • Low thermal conductivity and excellent heat insulation s& thermal insulation
  • Keep warmer in winter, cooler in summer
  • Foam Density:28 to 33 kg/m3 (or customized)
  • Dimension:4mm* 1350mm*40mts (or customized)
  • Color:grey, black,White
  • Usage:Roof, Wall, Floor
  • Structure:  Aluminum foil + XPE + Aluminum foil/ Aluminum foil + IXPE + Aluminum foil( or customized-e.g. woven fabric aluminum foil)







Our services
Factory direct selling with competitve price, sooner leadtime,better customized services.
Samples in stock can be arranged in one working day.
