Product Details:
|
| LDPE: | Crosslinked And All Color Customized | Color: | Customized |
|---|---|---|---|
| Density: | 25kg/m3 To 333kg/m3 | Thickness: | 0.5-100mm |
| Material: | PE | Feature: | Shock Absorption,excellent Buoyancy,low Water Absorption,High Flotation |
Closed-cell structure XPE foam / CTF foam
XPE foam is produced by compounding PE with some special padding and foaming material, then cross linking by foaming.
The XPE foam is a kind of polymer material with good and independent obturator foramen, and smoothly surface and good elasticity, meanwhile it is also full of high mechanics intensity and good heat insulation, good waterproof, well resistant to aging, to high temperature, to chemical corrosion and different environments.
The XPE foam can be processed, easy and complex ones are both ok, or it also can be compounded with some other material to conglutinate. Meanwhile, we can also produce the FR foams by changing the directions for producing chemicals or metallurgical products.
| Density (kg/m3) | Shore Hardnes (°) | Water Absorbtion (g/cm2)23℃±2℃,24h | Thermal Conductivity (w/m.k) |
| 200±30 | 60-70 | ≤0.2 | ≤0.095 |
| 125±15 | 50-60 | ≤0.2 | ≤0.084 |
| 100±10 | 45-50 | ≤0.3 | ≤0.073 |
| 66.7±8 | 35-45 | ≤0.3 | ≤0.065 |
| 50±6 | 30-35 | ≤0.4 | ≤0.055 |
| 40±4 | 25-30 | ≤0.4 | ≤0.049 |
| 33.3±3 | 18-25 | ≤0.5 | ≤0.045 |
| 28.6±3 | 13-18 | ≤0.5 | ≤0.040 |
1) Colorful soft play mat for Children , outdoor play mats for kids ,baby play mat.
2) material :PE foam ,high density foam inside.
3) Eco-friendly:6p-free,AZO-free,low lead, low cadnium, can reach EN71 standard
4) Usage:play mat for children, ground matress
5) Feature: all environmental material, can be folded, cleaned easily, durable.
6) Color:bright in color, red, yellow, blue, green, orange, purple to choose.
1. Heat Insulation: Single-foaming structure can reduce the loss of heat between air convections, suitable for making heat preservation pipes and boards. Good anti-dew capability, suitable for humid environments like refrigerators, air-conditioners and ice houses, etc.
2. Cushion Capability: Semi-hard quality foams have good rebound capabilities after strong impact, suitable for the packing of instruments, semi-conductors and electronics, etc.
3. Sound Absorption: Good sound and noise absorption capability, suitable for sound absorption and insulation parts of automobiles, electro-motors and other equipment and environments with loud noises.
4. Shaping Capability: Good heat endurance and ductility capability with even density, suitable for making deep interior parts like shaping in vacuum and hot environments, like the air conditioning vaporizing tank of automobiles, hot-shaped peak canopy of vehicles and shoes, etc.
5.Good chemical, oil, acid and alkali durability capabilities. It is safe and odorless, easy for machining and casting, and can be mixed with many other materials. It has a wide developing area as a new environmentally-safe material.
We complied with SGS, ROHS ,ISO9001,UL and other international standards.
CYG TEFA CO.,LTD established in December of 2002.
We are the leading manufacturer for XPE , IXPE foam,PE foam,ESD foam,IXPP foam for more than 20+ years, all our products can be used for thermal insulation,waterproof,shockproof,etc. and also our products get the UL, ISO, SGS, Rohs, Reach , CE approval. and we have 17 production lines for production.Hope to cooperate with you.
